This information covers only the differences in control functions for users to visually differentiate between the models.
The performance upgrades for the models are not covered in this information.
MP Model range version differences
V1 (No longer produced)
- Tri pole switch under the control box that enables Turbo Audio mode to the right, All Metal - center and Iron Reject to the left.
- Dual tone audio
V2 (No longer produced)
- Two pole switch under the control box that enables Iron Reject to the left and All Metal to the right.
- Sensitivity Control
- Single ground balance
- Dual tone audio
- Bi-Color RGB LED meter
- Dual mineral control
V3
- LC/MC Set control replaced Sensitivity control
- Adaptable recovery speed in the VCO (multi tones) audio.
- Multi-color RGB LED meter
- Dual ground balance
- Single mineral control
V3+
All features of the MP V3 with the following unique controls:
- Iron rejection / VCO switch - Iron rejection when pushed forward. When pulled back enables momentary VCO, returns to off state when released.
- Iron indicator on the RGB meter with Blue color.
